Universal grinding machine with two grinding wheels in opposite directions

Benefits at a glance

  • Low weight
  • Uneven running thanks to tool disks running in opposite directions
  • Level evenness thanks to a large working surface
  • Wide application area because of comprehensive accessories
  • Separating the tool and the drive
  • Continuous speed regulation makes it possible to adapt to the particular craft
  • High delivery rate
  • Compatible with rucksack vacuum, therefore great flexibility of movement

The inoPLAN Universal grinder is an all-rounder and is therefore light and convenient to use. The motor is easy to mount on the belt and power is transmitted via a flexible shaft. The hand piece of the versatile grinding machine is especially light, with two grinding disks which rotate in opposite directions. This ensures a smooth operation, while offering a large contact and grinding surface for even surfaces. Together with the optional backpack vacuum and comprehensive accessories, the inoPLAN Universal is able to master virtually any grinding job effortlessly.



inoPLAN Universal

Service details

Services
Operating voltageV/Hz/A230 / 50 / 16
Drive performancekW0,9
Grinding wheels (Ø)mm200
Rotational frequencyr/min120 - 600
Machine techniqueSpecial grinders
CommentsNo warranty claim when grinding without extraction!
* Weight motor additionally: 2,5 kg
Weightkgapprox. 2,4 *

Scope of delivery
inoPLAN Universal
Item no. 10019283

  • With dust suction hood
  • 1 pair of velour-backed support plates, diameter 200 mm
  • Plastic carry case
  • Operating instructions
  • Backpack vacuum (optional)
inoPLAN Universal
Smoothing plates / Application: Smoothing (pair, 200 mm diameter each)

Smoothing plates / Application: Smoothing (pair, 200 mm diameter each)

  • Concrete surfaces can be smoothed quickly and easily using the plastic smoothing discs. When it comes to surface treatment, it is important that the concrete floor has not yet completely set (sprayed concrete).

Smoothing plates / Application: Smoothing (pair, 200 mm diameter each) (Article No. 10019265)
Smoothing discs with steel blades / Application: Smoothing (pair, 200 mm diameter each)

Smoothing discs with steel blades / Application: Smoothing (pair, 200 mm diameter each)

  • For smoothing concrete and other surfaces (moist concrete, inside of silos)

Smoothing discs with steel blades / Application: Smoothing (pair, 200 mm diameter each) (Article No. 10019266)
Support plate with Velcro / Application: Grinding (pair, 200 mm diameter each)

Support plate with Velcro / Application: Grinding (pair, 200 mm diameter each)

  • For attaching sanding disks, abrasive mesh, metal abrasive discs and cleaning pads

Support plate with Velcro / Application: Grinding (pair, 200 mm diameter each) (Article No. 10019355)
Emery* / Application: Grinding, cleaning, roughing  (pair, 200 mm diameter each)

Emery* / Application: Grinding, cleaning, roughing (pair, 200 mm diameter each)

  • Surface grinding: Polystyrene insulation panels, rockwool strips and other full thermal insulation systems, panel joints, plaster rendering base
  • Cleaning formwork (for an absorbent lining), etc.
  • Roughing polystyrene surfaces

----------------------------------

* for use with support plate (Item no. 10019355)

Emery - K100 (Article No. 10008125-001)
Emery - K120 (Article No. 10008125-002)
Emery - K16 (Article No. 10008125-003)
Emery - K24 (Article No. 10008125-004)
Emery - K40 (Article No. 10008125-005)
Emery - K60 (Article No. 10008125-006)
Emery - K80 (Article No. 10008125-007)
Steel- and Nylon brushes / Application: Cleaning (pair, 200 mm diameter each)

Steel- and Nylon brushes / Application: Cleaning (pair, 200 mm diameter each)

  • Cleaning of shell elements, removal of loose plaster and paint

Nylon brushes, coarse (Article No. 10019310)
Nylon brushes, fine (Article No. 10019309)
Steel brushes, coarse (Article No. 10019351)
Steel brushes, fine (Article No. 10019350)
Steel brushes, medium (Article No. 10019352)
Steel/nylon brushes (Article No. Stahl-/Nylonbürsten)
Grinding fleece* / Application: Cleaning and polishing (pair, 200 mm diameter each)

Grinding fleece* / Application: Cleaning and polishing (pair, 200 mm diameter each)

  • For cleaning formwork and visible concrete, building and facade cleaning, polishing e.g. of marble effect and wood

---------------------------------------------

* for use with support plate (Item no. 10019355)

Grinding fleece K120*, medium (Article No. 10019333)
Grinding fleece K180*, fine (Article No. 10019334)
Grinding fleece K80*, coarse (Article No. 10019335)
“Long life” abrasive disc / Application: Scratches (pair, 200 mm diameter each)

“Long life” abrasive disc / Application: Scratches (pair, 200 mm diameter each)

  • Abrasive discs with pointed tips are used for doctoring sgraffito. The large contact surfaces guarantee safe and even work with abrasive discs.
  • Fibre-glass wallcoverings can also be opened with abrasive discs.

“Long life” abrasive disc / Application: Scratches (pair, 200 mm diameter each) (Article No. 10019295)
Widia discs / Application: Removing old plaster (pair, 200 mm diameter each)

Widia discs / Application: Removing old plaster (pair, 200 mm diameter each)

  • For removing sandy old plaster and for roughing dry plaster.
  • For milling away carpet and tile mortar adhesive and removing significant soiling from industrial floors.
  • Work rate for tile mortar: approximately 20 - 30 square metres per hour

Widia discs / Application: Removing old plaster (pair, 200 mm diameter each) (Article No. 10019374)
Rubbing board attachment (for use with base plate) / Application: Rubbing (pair, 200 mm diameter each)

Rubbing board attachment (for use with base plate) / Application: Rubbing (pair, 200 mm diameter each)

• Rubbing board attachments with blunt cutting surfaces are used for rubbing base plaster, gypsum and insulating plaster after they have been hardened.

Base plate for rubbing board attachment (pair, 200 mm diameter each) (Article No. 10019267)
Rubbing board attachment (for use with base plate) / Application: Rubbing (pair, 200 mm diameter each) (Article No. 10019316)
Backpack vacuum for complete freedom of movement

Backpack vacuum for complete freedom of movement

  • Large filter bags (15 l content), short hose distance, therefore considerable suction performance, no electronics susceptible to breakdown, sturdy and high-performance processing, additional socket in the device

Technische Daten

Motor rating 1.100 W
Weight 6.5 kg
Flow volume max. max. 60 l/s
Vacuum max. 190 mbar
Hopper volume 15 l
Dimensions 20 x 43 x 63 cm (L x W x H)

Backpack vacuum for complete freedom of movement (Article No. 10019277)
Paper filter bags, 15 l content

Paper filter bags, 15 l content

  • For fine dust, .e.g. gypsum, rock wool dust and normal building dust.

Paper filter bags, 15 l content (Article No. 10019312)
Material filter bag with zip fastener for emptying, 15 l content

Material filter bag with zip fastener for emptying, 15 l content

  • Only for polystyrene dust.

Material filter bag with zip fastener for emptying, 15 l content (Article No. 10019354)
Lamella filter

Lamella filter

  • Additional filter to protect the motor

Lamella filter (Article No. 10019297)
